CCNA 3 — ENSA · Modul 1 · OSPF · Subnetting

Router1# show ip route
Gateway of last resort is 10.10.11.2 to network 0.0.0.0

      209.165.200.0/27 is subnetted, 1 subnets
B        209.165.200.224 [20/0] via 10.10.12.2, 03:22:14
      209.165.201.0/27 is subnetted, 1 subnets
B        209.165.201.0 [20/0] via 10.10.12.2, 02:26:33
      209.165.202.0/27 is subnetted, 1 subnets
B        209.165.202.128 [20/0] via 10.10.12.2, 02:26:03
      10.0.0.0/8 is variably subnetted, 8 subnets, 4 masks
C        10.10.10.0/28 is directly connected, GigabitEthernet0/0
C        10.10.11.0/30 is directly connected, FastEthernet2/0
C        10.10.12.0/30 is directly connected, GigabitEthernet0/1
O        10.10.13.0/25 [110/2] via 10.10.10.1, 00:00:04, GigabitEthernet0/0
O        10.10.13.128/28 [110/2] via 10.10.10.1, 00:00:04, GigabitEthernet0/0
O        10.10.13.144/28 [110/2] via 10.10.10.1, 00:00:04, GigabitEthernet0/0
O        10.10.13.160/29 [110/2] via 10.10.10.1, 00:00:04, GigabitEthernet0/0
O        10.10.13.208/29 [110/2] via 10.10.10.1, 00:00:04, GigabitEthernet0/0
S*    0.0.0.0/0 [1/0] via 10.10.11.2
